Acland Approximator

Overview

The ACLAND Approximator is a approximator catalogued in the Vessel Clips, Approximators & Applying Forceps section of the Aesculap Surgical Instrument Catalog. It is supplied in the ACLAND pattern. This entry represents the complete product family, available in 16 configurations; the exact specification of each option is listed under its individual variation and summarised below.

How It Works

A vessel approximator carries two clips on a common frame so that two vessel ends can be occluded and then drawn together and held in apposition. Maintaining the ends in a fixed, aligned position frees the surgeon's hands and stabilises the field while the ends are joined. The clamping force and frame geometry determine the vessel size and gap the device suits.

Design Characteristics

Characteristics shared across this product family include curvature (straight (gerade)).

Configuration Options

The configurations differ by application (artery and vein), closing force (0.08 N – 0.12 N, 0.15 N – 0.19 N, 0.22 N – 0.32 N, 0.44 N – 0.56 N, and 0.85 N – 1.10 N), dimensions (1.10 mm; 1.50 mm; 1.70 mm; 2.20 mm; 2.90 mm), and configuration (standard and with bracket). Each option below is a separate catalogue reference:

• FD880R: artery, closing force 0.08 N – 0.12 N, 1.10 mm.
• FD881R: vein, closing force 0.08 N – 0.12 N, 1.10 mm.
• FD882R: artery, closing force 0.15 N – 0.19 N, 1.50 mm.
• FD883R: vein, closing force 0.15 N – 0.19 N, 1.50 mm.
• FD884R: artery, closing force 0.22 N – 0.32 N, 1.70 mm.
• FD885R: vein, closing force 0.22 N – 0.32 N, 1.70 mm.
• FD886R: artery, closing force 0.44 N – 0.56 N, 2.20 mm.
• FD887R: vein, closing force 0.44 N – 0.56 N, 2.20 mm.
• FD888R: artery, closing force 0.85 N – 1.10 N, 2.90 mm.
• FD889R: vein, closing force 0.85 N – 1.10 N, 2.90 mm.
• FD890R: artery, with bracket, closing force 0.08 N – 0.12 N, 1.10 mm.
• FD891R: vein, with bracket, closing force 0.08 N – 0.12 N, 1.10 mm.
• FD892R: artery, with bracket, closing force 0.15 N – 0.19 N, 1.50 mm.
• FD893R: vein, with bracket, closing force 0.15 N – 0.19 N, 1.50 mm.
• FD894R: artery, with bracket, closing force 0.22 N – 0.32 N, 1.70 mm.
• FD895R: vein, with bracket, closing force 0.22 N – 0.32 N, 1.70 mm.

Selection Guidance

When ordering, select the variation whose clamping size / closing force, application (artery or vein), and configuration matches the intended use. The corresponding catalogue reference and its stated specification are shown in the configuration list above.

Technical Specifications

Catalogued specifications: Pattern — ACLAND; Instrument Type — Approximator; Category — Vessel Clips, Approximators & Applying Forceps; Subcategory — Approximators; Manufacturer — Aesculap (B. Braun); Curvature — straight; Variation Count — 16; Closing Force Range — 0.08 N – 0.12 N; 0.15 N – 0.19 N; 0.22 N – 0.32 N; 0.44 N – 0.56 N; 0.85 N – 1.10 N; Application — artery and vein; Dimension Options — 1.10 mm; 1.50 mm; 1.70 mm; 2.20 mm; 2.90 mm; Configuration Options — standard and with bracket.

Compatibility

Catalogued companion references: To be used with FD896R, FD897R.

Applications

Supported uses derived from the instrument type and catalogued attributes: Approximation of vessel ends and Use on arteries and veins. The source catalog does not state specific surgical procedures or specialties, and none are implied here.

Identification and Traceability

This product is catalogued under reference(s) FD880R, FD881R, FD882R, FD883R, FD884R, FD885R, FD886R, FD887R, FD888R, FD889R, FD890R, FD891R, FD892R, FD893R, FD894R, FD895R on page(s) 557 of the Aesculap Surgical Instrument Catalog, and is registered under family FAM-000014 with the ACLAND pattern designation.

Reprocessing and Care

As a reusable surgical instrument, the Acland Approximator is intended to be reprocessed between uses in accordance with the manufacturer's instructions for use and the healthcare facility's validated procedures. Reprocessing typically comprises cleaning to remove all soil, thorough rinsing and drying, inspection for damage or corrosion, a functional check of the working parts, and sterilization by a validated method. Before each use the instrument should be examined for correct function and integrity, and any instrument that is damaged or does not operate correctly should be withdrawn from use. Compatible cleaning agents, reprocessing parameters, and sterilization methods should follow the manufacturer's validated instructions for use, and sterilized instruments should be stored in a clean, dry environment that maintains sterility until the point of use.

Procurement and Quotation

This family is supplied on a quotation basis rather than at a listed price. To obtain pricing, submit an inquiry through the Request a Quote or Send Inquiry option specifying the required configuration and the quantity required; a quotation will be returned with current pricing, availability, and lead time. For variable configurations, indicating the exact variation ensures the correct item is quoted. Product documentation, including the manufacturer's instructions for use, can be requested together with the quotation, and the supplier can advise on compatible companion instruments where the item is used as part of a set.
