Ball Electrode, Wire Loop Electrode

## Product Overview

Ball Electrode, Wire Loop Electrode is a ball electrode, wire loop electrode listed in the HF Instruments range of the Aesculap Surgical Instrument Catalog, page 1408. The source catalog is bilingual and prints the designation as Ball Electrode, Wire Loop Electrode in English and Kugelelektrode, Drahtschlingenelektrode in German, so either term can be used when matching this item against an existing inventory or tender list. This entry represents a single catalogued configuration, catalog number GK129R, and the specifications below are the values printed for that reference. It is classified in the catalog under Surgical Instruments > HF Instruments > Ball Electrode, Wire Loop Electrode.

## Design Characteristics

The following characteristics are printed for every configuration in this listing: length 125 mm, diameter 4 mm, second working-end diameter 6 mm, straight, insulated, monopolar, and length (imperial) 5″. Overall length is printed as 125 mm (5″ imperial). The printed working-end diameter is 4 mm. The working portion is printed as straight, which is the geometry the catalog specifies for this reference. The instrument is printed as insulated, which governs how it may be paired with an electrosurgical generator. The catalog prints the energy mode as monopolar, which determines the generator connection and cable configuration required. The catalog prints these descriptors bilingually: straight (gerade), insulated (isoliert), and long shaft (langer Schaft).

## Configuration Options

This instrument is catalogued as a single configuration under catalog number GK129R. The source catalog prints no alternative lengths, curvatures, diameters or sizes under this entry. Related configurations, where the catalog lists them, appear as separate entries in the HF Instruments range and are registered here as separate products. The printed specification for this reference is reproduced in full under Technical Specifications below.

## Technical Specifications

– **Instrument type:** Ball Electrode, Wire Loop Electrode
– **Length:** 125 mm
– **Diameter:** 4 mm
– **Second working-end diameter:** 6 mm
– **Curvature:** straight
– **Insulation:** insulated
– **Energy mode:** monopolar
– **Length (imperial):** 5″
– **Catalog category:** HF Instruments (GK)
– **Catalog numbers:** GK129R
– **Configurations:** 1
– **Family ID:** FAM-000061
– **Source:** Aesculap Surgical Instrument Catalog, p. 1408

## Specification Coverage

The source catalog prints overall length, working-end diameter, and curvature for this listing. It does not print edge, size code, material, working angle, shaft characteristic, and tip form; these values are omitted here rather than estimated, and can be confirmed on inquiry. This listing reproduces only what the manufacturer’s catalog states. No material, certification, performance or clinical claim is added.

## Ordering Information

Ball Electrode, Wire Loop Electrode is supplied on a request-for-quote basis; the catalog publishes no price. Quote catalog number GK129R when submitting an inquiry. Send an inquiry to confirm current availability, packaging and lead time, or to request a formal quotation. Contact us for procurement documentation, including catalog references for tender submissions.

## Source and Traceability

All specifications above are reproduced from the Aesculap Surgical Instrument Catalog, page 1408, HF Instruments section. Registry reference REG-000110; family FAM-000061. Values not printed in the source are omitted rather than estimated. For reference, the printed specification block for GK129R reads: · 5“, 125.00 mm · straight, gerade · monopolar · insulated, isoliert · long shaft, langer Schaft · 4.00 mm · 6.0 mm
