Cushing Vein Retractor

SKU: RG-001703 Category: General & Handheld Retractors

Configuration	205 mm (8") / 14 mm / 18 mm , 205 mm (8") / 10 mm / 13 mm , 175 mm (6 7/8") / 10 mm / 10 mm , 250 mm (9 3/4") / 11 mm / 14 mm , 250 mm (9 3/4") / 13 mm / 18 mm

Single-ended blade design
175 mm, 205 mm, and 250 mm length options
Multiple blade width and depth configurations
Reusable instrument with UDI direct marking

Configuration

Clear

Select Variation5 options

RG-001703205 mm (8") / 14 mm / 18 mm

RG-001703205 mm (8") / 10 mm / 13 mm

RG-001703175 mm (6 7/8") / 10 mm / 10 mm

RG-001703250 mm (9 3/4") / 11 mm / 14 mm

RG-001703250 mm (9 3/4") / 13 mm / 18 mm

2-year warranty

Cubilia vestibulum interdum nisl lorem at interdum posuere libero iaculis.

Free Shipping

Cubilia vestibulum interdum nisl lorem at interdum posuere libero iaculis.

Description
Additional information

The Cushing Vein Retractor is a single-ended surgical retractor with a blade-type working end and multiple size configurations. The supplied versions range from 175 mm (6 7/8″) to 250 mm (9 3/4″) in overall length, with blade widths from 10 mm to 18 mm and depths from 10 mm to 14 mm.

Single-ended blade design
175 mm, 205 mm, and 250 mm length options
Multiple blade width and depth configurations
Reusable instrument with UDI direct marking

Long Description

Product Overview

The Cushing Vein Retractor is a single-ended surgical retractor featuring a blade-type working end. The supplied product data includes five configurations with different overall lengths and blade dimensions.

The available configurations are:

205 mm (8″) with an 18 mm blade width and 14 mm blade depth
205 mm (8″) with a 13 mm blade width and 10 mm blade depth
175 mm (6 7/8″) with a 10 mm blade width and 10 mm blade depth
250 mm (9 3/4″) with a 14 mm blade width and 11 mm blade depth
250 mm (9 3/4″) with an 18 mm blade width and 13 mm blade depth

All supplied configurations are specified as reusable and have UDI direct marking. Two of the supplied configurations are specifically identified as non-sterile.

Instrument Design

The Cushing Vein Retractor has a single-ended configuration with a blade forming the working end. The supplied product data represents multiple dimensional configurations of the same product.

Working End / Blade

The working end is identified as a blade. The supplied blade dimensions vary according to configuration:

Configuration	Blade width	Blade depth
1	18 mm	14 mm
2	13 mm	10 mm
3	10 mm	10 mm
4	14 mm	11 mm
5	18 mm	13 mm

No additional blade characteristics, such as curvature, tip profile, serrations, or surface features, are specified.

Key Functional Features

Single-ended design
Blade-type working end
175 mm (6 7/8″), 205 mm (8″), and 250 mm (9 3/4″) length configurations
Blade widths from 10 mm to 18 mm
Blade depths from 10 mm to 14 mm
Reusable instrument
UDI direct marking
Non-sterile specification for two supplied configurations

Handle and Shaft

The supplied specifications identify the Cushing Vein Retractor as single ended but do not provide separate details regarding the handle or shaft, including their dimensions, shape, or construction.

Dimensions

The Cushing Vein Retractor is supplied in three overall length options:

175 mm (6 7/8″)
205 mm (8″)
250 mm (9 3/4″)

The complete dimensional configurations are:

Configuration	Overall length	Blade width	Blade depth
1	205 mm (8″)	18 mm	14 mm
2	205 mm (8″)	13 mm	10 mm
3	175 mm (6 7/8″)	10 mm	10 mm
4	250 mm (9 3/4″)	14 mm	11 mm
5	250 mm (9 3/4″)	18 mm	13 mm

Material

The Cushing Vein Retractor is made from German stainless steel.

Finish

The finish is not specified in the supplied product information.

Reusability, Sterility and UDI Marking

The Cushing Vein Retractor configurations are specified as reusable and have UDI direct marking.

Two supplied configurations are explicitly identified as non-sterile. Sterility is not separately specified for the other configurations.

Applications

The Cushing Vein Retractor is listed across the following disciplines:

General / Visceral Surgery
Gynaecology
Cardiac / Thoracic Surgery
Neurosurgery
Urology
Vascular Surgery
Pediatric Surgery
Hand / Foot Surgery
Ear-Nose-Throat Surgery
Maxillo-Facial Surgery
Orthopaedics / Traumatology
Plastic Surgery
Spine Surgery

Specifications

Specification	Details
Product name	Cushing Vein Retractor
Instrument type	Surgical retractor
Design	Single ended
Working end type	Blade
Blades / jaw	Blade
Overall length options	175 mm (6 7/8″); 205 mm (8″); 250 mm (9 3/4″)
Blade width options	10 mm; 13 mm; 14 mm; 18 mm
Blade depth options	10 mm; 11 mm; 13 mm; 14 mm
UDI direct marking	Yes
Disposable / reusable	Reusable
Sterility	Non-sterile for specified configurations
Discipline	General / Visceral Surgery; Gynaecology; Cardiac / Thoracic Surgery; Neurosurgery; Urology; Vascular Surgery; Pediatric Surgery; Hand / Foot Surgery; Ear-Nose-Throat Surgery; Maxillo-Facial Surgery; Orthopaedics / Traumatology; Plastic Surgery; Spine Surgery
Material	German stainless steel
Finish	Not specified

Product Identification

The Cushing Vein Retractor is identified by its single-ended blade working end and multiple dimensional configurations. The supplied overall lengths are 175 mm (6 7/8″), 205 mm (8″), and 250 mm (9 3/4″), with blade widths ranging from 10 mm to 18 mm and blade depths ranging from 10 mm to 14 mm.

Configuration	205 mm (8") / 14 mm / 18 mm , 205 mm (8") / 10 mm / 13 mm , 175 mm (6 7/8") / 10 mm / 10 mm , 250 mm (9 3/4") / 11 mm / 14 mm , 250 mm (9 3/4") / 13 mm / 18 mm
