Gosset Abdominal Retractor – Self-Retaining Complete Retractor

Product Overview

The Gosset Abdominal Retractor is a self-retaining complete surgical retractor designed with multiple dimensional configurations for the supplied abdominal surgery range. The product data includes small, medium, and large configurations, with overall lengths of 125 mm (5″), 200 mm (7 7/8″), and 175 mm (6 7/8″), respectively. The small configuration provides a 75 mm opening width, a 29 mm jaw width, and a 38 mm jaw depth, while the medium configuration has a 38 mm jaw width and 55 mm jaw depth. The large configuration measures 175 mm (6 7/8″), with a 150 mm opening width, 38 mm jaw width, and 58 mm jaw depth. Ratchet bar lengths are specified as 115.00 mm, 200.00 mm, and 200.00 mm for the small, medium, and large configurations. The supplied system also includes a center blade measuring 150 mm (6″) in length, with a 57 mm blade width and 59 mm blade depth. The listed disciplines are General / Visceral Surgery, Gynaecology, and Pediatric Surgery, with the center blade also specified for these disciplines. The complete retractor configurations and center blade are identified as reusable.

Instrument Design and Working End

The Gosset Abdominal Retractor is specified as a complete retractor with a self-retaining configuration. The supplied size options provide different opening and jaw dimensions.

The small configuration measures:

• 125 mm (5″) overall length
• 75 mm opening width
• 29 mm jaw width × 38 mm jaw depth
• 115.00 mm ratchet bar

The medium configuration measures:

• 200 mm (7 7/8″) overall length
• 38 mm jaw width × 55 mm jaw depth
• 200.00 mm ratchet bar

The large configuration measures:

• 175 mm (6 7/8″) overall length
• 150 mm opening width
• 38 mm jaw width × 58 mm jaw depth
• 200.00 mm ratchet bar

Center Blade

A separate center blade configuration is supplied with a length of 150 mm (6″), a 57 mm blade width, and a 59 mm blade depth. It is specified for use within the Gosset Abdominal Retractor system and is listed for General / Visceral Surgery, Gynaecology, and Pediatric Surgery.

Dimensions

The main retractor configurations range from 125 mm to 200 mm in overall length. The supplied opening widths are 75 mm and 150 mm, while jaw widths range from 29 mm to 38 mm and jaw depths from 38 mm to 58 mm. The center blade provides a separate 57 mm × 59 mm working-end dimension.

Applications

The supplied discipline information includes:

• General / Visceral Surgery
• Gynaecology
• Pediatric Surgery

Specifications

Product Identification

The Gosset Abdominal Retractor is identified by its self-retaining complete retractor design, three supplied size configurations, and additional center blade:

Small / 125 mm (5″) / 75 mm / 29 mm / 38 mm | Medium / 200 mm (7 7/8″) / 38 mm / 55 mm | Large / 175 mm (6 7/8″) / 150 mm / 38 mm / 58 mm | Center blade / 150 mm (6″) / 57 mm / 59 mm
